Galimybių paso QR skaitytuvas


Galimybių paso QR  kodo skaitytuvas

QR kodas | NFC | 4G | Spausdintuvas (opcija)

Stacionarus QR kodų skaitytuvas (nereikia artimai kontaktuoti su klientu ) greitai nuskaito (QR) kodą užtikrindamas greitą ir saugų patekimą į patalpas.


Gali būti plačiai naudojamas bendruomenėje – paslaugų salėje, prekybos centre, stotyje, oro uoste, viešbutyje,  bažnyčioje ir kt.




OS Android 7.1 or above
Procesorius Quad-Core 1.1GHz or above
Atmintis 1GB DDR, 8GB eMMC, Ext. TF card slot
2GB DDR, 16GB eMMC (Optional)
Ekranas 5-inch, 1280*720 or above
Terminis spausdintuvas (Opcija) Paper width 58mm, Φ40mm
Bevielių kortelių skaitytuvas (Opcija) ISO14443 Type A/B, Mifare, ISO18092 compliant
 1D/2D Barkodų skaitytuvas Soft Decoding
Hard Decoding (Optional)
Komunikacijos Ethernet/WiFi/Bluetooth
Portai 2 USB Host, 1 micro USB, 1 RJ45, 1 RJ11
Audio Digital Audio Speaker
Maitinimo šaltinis 9V/2.5A
Baterija 7.4V/2500mAh, Li-ion (Optional)
Kiti 1 Power Key
Sertifikatas CE

QR kodo skaitytuvas su valdymo rėle .



Item Specification Item Specification
OS Android 8.1 or above
Linux (Optional)
Peripheral Ports 1 DC Input, 1 Micro USB, 1 RJ45, 1 Wiegand, 1 RS485, 1 Relay
Processor Octa-Core 1.8GHz or above Audio Digital Audio Speaker, Microphone
Memory 2GB DDR, 16GB eMMC
3GB DDR, 32GB eMMC (Optional)
Power Supply 12V/2A
Display 5.5-inch, 720*1280 Bracket (Optional) Wall Mount Bracket, Turnstile Mount Bracket
Keypad 1 Reset Key Dimensions (mm) 188 (L)*94 (W)*27 (H)
Camera Single-lens Camera (RGB), 2MP
Dual-lens Camera (RGB+IR), 2MP+1.3MP (Optional)
3D Depth Sensing Camera (Optional)
Operating temperature -5℃ ~ 45℃
Fill Light White LED Storage temperature -25℃ ~ 60℃
Contactless Card Reader (Optional) ISO14443 Type A/B, Mifare, ISO18092 compliant MDM (Optional) Mobile Device Management
Communications Ethernet/WiFi/Bluetooth
Certification CE, BIS

YouTube rolling out Picture-in-Picture mode for iOS, but there's a catch | Technology News,The Indian Express


Mobilus Galimybių paso QR  kodo skaitytuvas mobilus

Mobilus  QR kodų skaitytuvas – įmontuotas 2D kodo skaitytuvas  greitai nuskaito (QR) kodą užtikrindamas greitą ir saugų patekimą į patalpas.

Gali būti plačiai naudojamas bendruomenėje – paslaugų salėje, prekybos centre, stotyje, oro uoste …


Physical Characteristics
Dimensions 163.8 x 79.2 x 13.8 mm / 6.45 x 3.12 x 0.54 in.
Weight < 242 g / 8.5 oz.
Display 5.2” IPS FHD 1920 x 1080P
Touch Panel Corning Gorilla Glass, multi-touch panel, gloves and wet hands supported
Power Main battery: Li-ion, rechargeable, 4000mAh
Standby: over 300 hours
Continuous use: over 12 hours (depending on user environment)
Charging time: 2-3 hours (with standard adaptor and USB cable)
Expansion Slot 1 slot for Nano SIM card, 1 slot for Nano SIM or TF card
Interfaces USB2.0 Type-C, OTG
Audio Speaker, 2 microphones
Keypad 4 front buttons, 1 side button, 2 scan keys, 1 multifunctional key
Sensors Gravity sensor, Light Sensor, Proximity Sensor, Vibration Motor
WLAN IEEE802.11 a/b/g/n, 2.4G/5G dual-band, internal antenna
WWAN Android 8.1:
WWAN (China):
2G: 900/1800MHz
3G: WCDMA: B1,B8
4G: B1,B3,B5,B8,B34,B38,B39,B40,B41WWAN (Europe):
2G: 850/900/1800/1900 MHz
3G: B1/B2/B4/B5/B8
4G: B1/B3/B5/B7/B8/B20/B40WWAN(America):
2G: 850/900/1800/1900 MHz
3G: B1/B2/B4/B5/B8
4G: B2/B4/B7/B12/B17/B25/B66

Android 11.0:
2G: GSM850/GSM900/DCS1800/PCS1900
3G: WCDMA:B1/B2/B4/B5/B8

WWAN (Others) Depending on the country’s ISP
Bluetooth Android 8.1: Bluetooth v2.1+EDR,3.0+HS,v4.1+HS
Android 11.0: Bluetooth 5.0
GNSS GPS/AGPS, GLONASS, BeiDou; internal antenna
Note *C70 models being manufactured for Turkish Market, do not include Voice Call (Phone Call) function. WAN module included on those models only support DATA transfer.
Developing Environment
Operating System Android 8.1 / 11.0; GMS, Soti MobiControl, SafeUEM supported
SDK Chainway Software Development Kit
Language Java
Tool Eclipse / Android Studio
CPU Cortex-A53 2.5 / 2.3 GHz Octa-core
RAM+ROM 3 GB + 32 GB / 4 GB + 64 GB
Expansion Supports up to 128 GB Micro SD card
User Environment
Operating Temp. -4°F to 122°F / -20°C to 50°C
Storage Temp. -40°F to 158°F / -40°C to 70°C
Humidity 5%RH – 95%RH non condensing
Drop Specification Multiple 1.8m/5.9ft drops (at least 20 times) to the
concrete across the operating temperature range
Tumble Specification 1000 x 0.5m/1.64ft falls at room temperature
Sealing IP65 per IEC sealing specifications
ESD ±15KV air discharge, ±6KV conductive discharge
Barcode Scanning
2D Imager Scanner Zebra SE4710 / Honeywell N6603
1D Symbologies UPC/EAN, Code128, Code39, Code93, Code11, Interleaved 2 of 5, Discrete 2 of 5, Chinese 2 of 5, Codabar, MSI, RSS, etc.
2D Symbologies PDF417, MicroPDF417, Composite, RSS, TLC-39, Datamatrix, QR code, Micro QR code, Aztec, MaxiCode; Postal Codes: US PostNet, US Planet, UK Postal, Australian Postal, Japan Postal, Dutch Postal (KIX), etc.
Note *This function is optional
Camera 13MP autofocus rear camera with flash, optional 5MP front camera
Frequency 13.56 MHz
Protocol ISO14443A/B, ISO15693, NFC-IP1, NFC-IP2, etc.
Chips M1 card (S50, S70), CPU card, NFC tags, etc.
Range 2-4cm
